Siemens-SIMATIC-HMI-TP1200-Comfort-Panel-12-Inch-Widescreen-Touch

Siemens SIMATIC HMI TP1200 Comfort Panel 12" Touch | 6AV2124-0MC01-0AX0

SIMATIC HMI TP1200 Comfort, Comfort Panel, touch operation, 12" widescreen TFT display, 16 million colors, PROFINET interface, MPI/PROFIBUS DP interface, 12 MB configuration memory, Windows CE 6.0, configurable from WinCC Comfort V11

Feature	Specification
Display Size	12.1 inch TFT Widescreen
Resolution	1280 x 800 Pixels (High Definition)
Input Type	Touch Screen Operation
Interfaces	1 x PROFINET (2-port switch), 1 x PROFIBUS/MPI
USB Ports	2 x USB 2.0
Memory	12 MB User Memory (expandable via SD card)
Configuration	WinCC Comfort (TIA Portal)

Rs.226,000.00 Rs.566,929.00

Model

6AV21240MC010AX0

Available Offer

Product Details

Display: 12.1" widescreen TFT, 1280x800 pixel resolution, 16 million colors, backlight dimmable 0-100%

FAQ QUESTION

Q: What software is needed to program TP1200 Comfort?A: You need SIMATIC WinCC Comfort (TIA Portal) V11 or higher to configure this HMI.

Q: Can I use an SD card for data logging?A: Yes, it has two SD card slots—one for system data and one for data logging/archives.

Q: Is the 6AV2124-0MC01-0AX0 the same as the newer versions?A: This is a standard Comfort Panel model. Always check for specific firmware compatibility if you are replacing an older unit.
