Siemens-SINAMICS-S120-CU320-2-PN-Control-Unit-6SL3040-1MA01-0AA0

Siemens SINAMICS S120 Control Unit CU320-2 PN | PROFINET | 6SL3040-1MA01-0AA0

Name: Siemens SINAMICS S120 Control Unit CU320-2 PN | PROFINET | 6SL3040-1MA01-0AA0
Brand: SIEMENS
SKU: 6SL30401MA010AA0
Price: 151228.0 INR
Availability: InStock

SINAMICS CONTROL UNIT CU320-2 PN WITHOUT COMPACT FLASH CARD (6SL3040-1MA01-0AA0)

Feature,Specification

Control Unit Type,CU320-2 PN (PROFINET Interface)

Communication,"PROFINET, EtherNet/IP, Ethernet, RS232"

Digital Inputs,12

Bidirectional I/O,8 (Parameterizable as DI or DO)

DRIVE-CLiQ Ports,4

Power Supply,24V DC (20.4 to 28.8 V)

Dimensions (WxHxD),50.0 mm x 300.0 mm x 226.0 mm

Rs.151,228.00 Rs.160,000.00

Available Offer

Product Details

SINAMICS CONTROL UNIT CU320-2 PN WITHOUT COMPACT FLASH CARD

Q: Does this unit include the CompactFlash card?A: No. The Siemens 6SL3040-1MA01-0AA0 is supplied without a CompactFlash card. The firmware and parameters must be stored on a card (ordered separately).
Q: Can I use this with PROFIBUS systems?A: This specific model (PN) is for PROFINET. For PROFIBUS connectivity, you would need the 6SL3040-1MA00-0AA0 (CU320-2 DP) model.
Q: What software is used for commissioning?A: You can use the STARTER commissioning tool or the Startdrive package integrated within TIA Portal.
