SIMATIC DP, CPU 1510SP-1 PN for ET 200SP, central processing unit with work memory 100 KB for program and 750 KB for data, 1st interface: PROFINET IRT with 3-port switch, 72 ns bit performance, SIMATIC Memory Card required, BusAdapter required for port 1 and 2
Q: What is the main difference between this and the CPU 1512SP-1 PN?A: The 1510SP (this model) has 100 KB program memory, while the 1512SP has 400 KB. If your program is small, this 1510 model is much more economical.
Q: Do I need a special base for this?A: No, it mounts directly onto the standard ET 200SP DIN rail system, but you will need a Server Module (usually included with the CPU or sold separately) to terminate the backplane bus.
Q: Which software version is required?A: It requires STEP 7 Professional (TIA Portal). Version V13 or higher is typically needed, depending on the firmware version.
