Siemens-S7-400-SM-431-16-Channel-Analog-Input-6ES7431-7QH00-0AB0

Siemens SIMATIC S7-400 SM 431 Analog Input Module | 16 AI | 16-Bit | 6ES7431-7QH00-0AB0

SIMATIC S7-400, SM 431,(6ES74317QH000AB0)

Feature	Specification
Number of Inputs	16 Channels (High Density)
Resolution	16 Bits (Ultra High Precision)
Input Types	Voltage, Current, Thermocouples (TC), RTDs
Support for RTDs	Yes (Pt100, Ni100, etc.)
Support for TCs	Yes (Type J, K, L, T, U, N, E, R, S, B)
Isolation	Galvanic isolation between channels and backplane
Front Connector	Requires 48-Pin Connector

Rs.361,906.00 Rs.370,000.00

Available Offer

Product Details

SIMATIC S7-400, analog input SM 431, isolated 16 AI; resolution 16 bit, U/I/Resistor/Thermocouple/Pt100 , alarm, diagnostics

Q: Can I mix different sensor types on the same module?A: Yes, you can configure different groups of channels for different signal types (e.g., 8 channels for 4-20mA and 8 channels for Thermocouples) using the hardware configuration in Step 7 or TIA Portal.

Q: Is this module hot-swappable?A: When used with an active backplane bus in an S7-400 rack, it supports hot-swapping (insert/remove under power), provided your rack configuration allows it.

Q: What is the main difference between this and the 1KF20 model?A: The 7QH00 has 16 channels (vs 8), higher 16-bit resolution (vs 14), and direct support for Thermocouples and RTDs, which the 1KF20 lacks.
