Siemens SIMATIC S7-300 FM 353 Positioning Module for Stepper Motors | 6ES7353-1AH01-0AE0

SIMATIC S7-300, FUNCTION MODULE FM 353

Feature	Specification
Application	Positioning with Stepper Motors
Operating Modes	Setup, MDI, Automatic, Incremental
Pulse Frequency	Up to 200 kHz
Number of Axes	1 Axis control per module
Digital Inputs/Outputs	4 DI / 4 DO (Integrated for limit switches/drive signals)
Connector Type	20-Pin Front Connector (Required)

Rs.45,000.00

Available Offer

Product Details

SIMATIC S7-300, FUNCTION MODULE FM 353, FOR POSITIONING WITH STEPPER MOTOR
FAQ SECTION

Q: Can I use FM 353 for Servo Motors?A: No, the FM 353 is specifically for Stepper Motors. For Servo Motor control, you should use the FM 354 (6ES7354-1AH01-0AE0).

Q: Does it require any special software?A: Yes, you need the FM 353 configuration package (software tool) to set up the parameters in Step 7 or TIA Portal.

Q: How many axes can one FM 353 control?A: One module can control 1 Axis. For multi-axis machines, you can add multiple modules to the S7-300 rack.
