Siemens SIMATIC S7-300 SM 332 - 6ES7332-5HF00-0AB0 | 8-Channel Analog Output Module

SIMATIC S7-300, analog output SM 332, isolated, 8 AO, U/I; diagnostics; resolution 11/12 bit,(6ES73325HF000AB0)

Feature	Specification
Output Channels	8 Analog Outputs
Resolution	11 / 12 Bits (Programmable)
Output Types	Voltage and Current
Voltage Range	1-5V, 0-10V, ±10V
Current Range	0-20mA, 4-20mA, ±20mA
Isolation	Optically isolated in groups of 8
Connector Type	40-Pin Front Connector (Required)

Rs.216,960.00

Available Offer

Product Details

SIMATIC S7-300, analog output SM 332, isolated, 8 AO, U/I; diagnostics; resolution 11/12 bits, 40-pole, removing and inserting with active backplane bus possible

Q: What front connector is used for 6ES7332-5HF00-0AB0?A: This 8-channel module requires a 40-pin front connector. Note that the 4-channel version uses a 20-pin connector, so they are not interchangeable.
Q: Can this module provide a 4-20mA signal?A: Yes, it is fully compatible with 4-20mA, 0-20mA, and 0-10V industry-standard signals.
Q: Is this module compatible with TIA Portal?A: Yes, it is a standard S7-300 module and can be configured in both Step 7 V5.x and TIA Portal.
