Siemens-3SB5000-2AB01-2-Position-Selector-Switch-Actuator-Black

Siemens 3SB5000-2AB01 Selector Switch Actuator | 22.5mm | 2-Position | Latching

The Siemens 3SB5000-2AB01 is a 22 mm round, black selector switch actuator designed for industrial control panels. It is a maintained operation switch, meaning it stays in the selected position until manually moved

Feature	Specification
Diameter	22.5 mm
Number of Positions	2 Positions (0 - 1)
Switching Angle	90°
Actuation Type	Latching / Maintained (Stay-put)
Color	Black
Material	Plastic
IP Rating	IP65 (Weatherproof)

Rs.400.00

Available Offer

Product Details

The Siemens 3SB5000-2AB01 is a 22 mm round, black selector switch actuator designed for industrial control panels. It is a maintained operation switch, meaning it stays in the selected position until manually moved

Q: Is the 3SB5000-2AB01 a momentary or maintained switch?A: This is a Maintained (Latching) switch. Once turned to a position, it stays there until manually turned back.

Q: Does it come with the contact block and holder?A: No, this is the actuator head only. You need to buy the holder and NO/NC contact blocks separately for the complete assembly.

Q: Can I use this for 3-position switching?A: No, this model is only for 2-positions. If you need 3-positions (1-0-2), you should look for the 3SB5000-2BC01 model.
