Siemens SIRIUS 3RU2126-1DB0 Thermal Overload Relay | 2.2...3.2 A | Size S0

Overload relay 2.2...3.2 A Thermal For motor protection Size S0, Class 10 Contactor mounting Main circuit: Screw Auxiliary circuit: Screw Manual-Automatic-Reset

Feature	Specification
Current Setting Range	2.2 ... 3.2 A
Frame Size	S0 (Direct Mounting)
Trip Class	CLASS 10
Auxiliary Contacts	1 NO + 1 NC
Main Circuit Connection	Screw Terminals
Mounting	Direct mounting on S0 Contactors (3RT202 series)

Rs.7,000.00

Available Offer

Product Details

Overload relay 2.2...3.2 A Thermal For motor protection Size S0, Class 10 Contactor mounting Main circuit: Screw Auxiliary circuit: Screw Manual-Automatic-Reset

Q: Is 3RU2126-1DB0 compatible with Size S00 contactors?A: No, this relay is for Size S0. For Size S00, you would need the 3RU2116 series.
Q: Can I use this for a 3-phase motor?A: Yes, it is specifically designed for 3-phase AC motors to provide overload and phase loss protection.
Q: What contactors fit with this relay?A: It is compatible with all Siemens 3RT202 series contactors (Size S0), such as 3RT2024, 3RT2025, or 3RT2026.
