Siemens 6ES7132-6HD01-0BB1 | SIMATIC ET 200SP Digital Output Module DQ 4x24VDC/2A Standard
SIMATIC ET 200SP, Relay module, RQ NO 4x 120V DC..230VAC/5A ST. 4 normally open contacts
Module Type: Digital Output (DQ).
Series: SIMATIC ET 200SP.
Number of Channels: 4.
Output Type: Transistor (Source/PNP).
Rated Voltage: 24V DC.
Output Current:2.0 A per channel (Note: This is higher than the standard 0.5A modules, making it ideal for larger loads).
Total Current: Max 8A per module.
BaseUnit Compatibility: Fits BU Type A0.
Color Code: CC02.
Diagnostics: Short-circuit protection, wire-break monitoring, and supply voltage diagnostics.
Rs.7,355.60
Available Offer
Share :
Product Details
SIMATIC ET 200SP, Relay module, RQ NO 4x 120V DC..230VAC/5A ST. 4 normally open contacts, isolated contacts, packing unit: 1 piece, fits to BU-type B0 and B1, Colour Code CC40, substitute value output, module diagnostics for: supply voltage
